Association of Axial Length With Risk of Uncorrectable Visual Impairment for Europeans With Myopia

Posted on September 7th 2020 by Ailsa Lane key paper.png

Authors: J. Willem L. Tideman (1,2), Margaretha C.C. Snabel (3), Milly S. Tedja (1,2), Gwyneth A.van Rijn (4), King T.Wong (1), Robert W.A.M Kuijpers (1,5), Johannes R. Vingerling (1,2), Albert Hofman (2), Gabrielle H.S. Buijtendijk (1,2), Jan E.E. Keunen (6), Camiel J.F. Boon (4), Annette J.M. Geerards (7), Gergorius P.M Luyten (4), Virginie J.M. Verhoeven (1,2,8), Caroline C.W. Klaver (1,2)

  1. Department of Ophthalmology, Erasmus Medical Centre, Rotterdam, the Netherlands
  2. Department of Epidemiology, Erasmus Medical Centre, Rotterdam, the Netherlands
  3. Department of Ophthalmology, University Medical Centre Utrecht, Utrecht, the Netherlands
  4. Department of Ophthalmology, Leiden University Medical Centre, Leiden, the Netherlands
  5. Department of Ophthalmology, Albert Schweitzer Hospital, Dordrecht, the Netherlands
  6. Department of Ophthalmology, Radboud University Medical Centre, Nijmegen, the Netherlands
  7. The Rotterdam Eye Hospital, Rotterdam, the Netherlands
  8. Department of Clinical Genetics, Erasmus Medical Centre, Rotterdam, the Netherlands

Date: December 2016

Reference: JAMA Ophthalmol 2016;134(12):1355-1363 - LINK


Myopia is increasingly frequent in many developed countries and we now know it isn’t simply a matter of poor vision which we ‘fix’ with spectacles or contact lenses.  It can lead to myopic maculopathy, glaucoma, cataract and retinal detachment and having 'high' myopia increases these risks further.  These eye conditions can all potentially lead to reduced vision at best and blindness at worst.  As myopia increases, the eye’s total axial length has been seen to increase too, and it is this elongation which leaves the eye at risk from ocular pathologies.

The classification of what constitutes ‘high’ myopia can vary.  The World Health Organisation (WHO) decided on a threshold of -5.00D and stronger in 2015 (1).   For the purposes of their study, Tideman et al classed participants as being highly myopic when they had a spherical equivalent (SE) of -6.00D and an axial length (AXL) of 26mm or more.

This study used cross-sectional data collected from population-based studies undertaken by the Rotterdam study (I, II & III) and the Erasmus Rucphen Study.  These results were combined with case-control data from the Myopia Study, with participants across all studies being 25 years or older.  The authors wished to explore a link between visual impairment as a result of increased AXL, refractive error and to be able to apply this to the wider population.

Clinical relevance

It’s all about the risk

  • We can see how myopia is likely to be a leading cause of blindness in the near future after the study findings suggest that “visual impairment will increase 7- to 13-fold by 2055 in high-risk areas”.
  • We can also be more aware of an individual’s risk when we can see that those with an AXL of 26mm or greater. Those with longer axial length had a higher chance of having myopic-linked vision impairment - this increased from a 3.8% chance if the AXL was less than 26mm to a 25% chance if the AXL was 26mm or longer.  An AXL of 30mm or longer was associated with a 90% chance of vision impairment in their lifetime due to complications from myopia.
  • Eye Care Professionals are in a prime position to communicate this robust information we have on the risks associated with increased myopia and what their options are to reduce that risk.
  • Start considering myopia management early.
    • The participants who were most at risk of visual impairment were in the older age group and they had therefore had longer eyes and higher myopia for a longer time.
  • Don’t forget the lower myopes!
    • We need to consider all myopes as potentially being at risk of axial elongation and an increasing risk of impairment later in life, as we know from this and other studies that those who ‘only’ have -1.00D refractive error will already have double the risk of myopic maculopathy and posterior sub-capsular cataract compared to an emmetrope.(2)

Limitations and future research

This is a robust analysis taking in the data of more than 15,000 individuals, across multiple studies. The key area for future research is to measure how myopia control interventions for today's generation influence their rates of pathology and vision impairment in the future. This is a very long-term question, as our current generation of children with access to myopia management will need to age another 50-60 years before their outcomes could be compared to the ages analyzed in this paper. To this point, the authors recognized that their calculated risk estimates will become overstated with adoption of (successful) myopia strategies to slow myopia progression.

Race specific studies: The authors made predictions of varying prevalence for different countries, but these were based on values originally gathered from Europeans and they were aware this may not be directly applicable to other ethnicities.  They were able to allow for this by using reported prevalence estimates for each country.  At the time of publishing (2016), Tideman et al were unaware of any likely ethnic differences and felt confident they were making feasible predictions. Similar research across different ethnicities would help determine whether this observation holds true.

Changes in prevalence: The study revealed a steady shift from hyperopia to myopia when they looked at the birth decades of the participants, particularly from 1920 onward, with a higher myopic prevalence in the younger group (25yrs to 60yrs). This suggested that the population had been getting more myopic with time and that the chance of impairment with age was increasing alongside it. The authors predicted that by 2055 there would be a 2 to 3-fold increase risk of visual problems in Europe, a 3 to 5-fold chance in Singapore and a 3 to 6-fold in the Republic of Korea. This was based on their findings where the last study to be included in their analysis was from 2012. It is possible that the likelihood of myopic pathologies could have increased beyond their expectations since then. Further follow-on studies could verify if this has changed significantly.

Full story


The total axial length of the eye is taken from the most anterior part of the corneal surface to the furthest point at the back of the globe and there has long been an association with the length of the eye and myopia.  There has also been an increasing awareness over many years between the extent of the myopia itself and ocular pathologies arising from it such as myopic maculopathy and torn/detached retinas.  The authors of this study wanted to prove a link between the axial length and refractive error of the eye, and the likelihood of myopic pathologies with age.

Study design

Tideman et al collated data from the population-based Rotterdam Studies with Study I (1990-93), Study II (2000-02) and Study III (2006-08) and combined them with findings from the Erasmus Ruchpen Family study (2002-05, also population-based) and the Myopia Study (2010-12, case control data).  This gave information on the refractive error, axial length and age of 15,693 individuals.

The participants were adults only with an age range of 25yrs to 75yrs and over, with a mean age of 61.3 yrs.  Across the cohort, axial length varied from 15.3mm to 37.8mm and the refractive error ranged from +14.00D to -25.00D as a spherical equivalent (SE).  The number of those with ‘high’ myopia of -6.00D or stronger was 796.  The axial lengths were available for 9,074 people after AXL measuring was undertaken at a later stage in the Rotterdam studies and some of the participants from the Myopia Study were excluded from the data for the AXL and SE due to the study design.


The prevalence of vision impairment was found to vary from between 1.0% - 4.1% in the population-based studies and 5.4% in the Myopia Study.  This was all compared to the control prevalence which was 0.3%.

Logistic regression techniques were used to calculate the odds ratio (OR) for visual impairment that would arise as a result of AXL and the refractive error.  For having a 26-28mm axial length, the under 60yrs group had double the risk of the reference group who had 24-26mm length, compared to the over 60yrs group that had a 3x risk for the same AXL.  The statistics then took a large jump with the under 60yrs group having an 11x chance for a 28-30mm AXL and 25x for if it was over 30mm.  The over 60yrs group showed a similar jump with the 28-30mm AXL, but they then showed around a 94x risk if the AXL was 30mm or more.

For the SE (in dioptres), there was a similar jump in results.  For refractive error between -3.00D to -15.00D, there was a 1.5x to 6.8x risk of visual impairment for the under 60s, and the same refractive range showed similar for the over 60s with between 1.7x to 7.8x risk.  It was when the refractive error was -15.00D or higher there was more difference where the younger age group had 28x risk, compared to nearly 88x for the older group.

The AXL and the refractive error were significantly related to each other, but also to impairment likelihood.  Of those who had been classed as having high myopia, 39% had developed some form of visual impairment caused by their myopia by the age of 75yrs old.  Those with longer axial length had a higher chance of having myopic-linked vision impairment and this increased from a 3.8% chance if the AXL was less than 26mm to a 25% chance if the AXL was 26mm or longer.  An AXL of 30mm or longer was associated with a 90% chance of vision impairment in their lifetime due to complications of myopia.


The worrying findings from this analysis are significant in explaining the realistic probabilities of ocular conditions arising from high myopia and increased AXL.  The authors suggested that those at the stronger end of the myopic scale may find their risk is “unavoidable” as we currently have no treatments that halt or reverse the impairments high myopia can give – sadly the damage is already done.

However, the older age group in the study (60+yrs or more) wouldn’t have had the myopia management options we have now for intervening with their myopic progression in their youth when they needed it.  If myopia and its risk of visual problems has a higher prevalence and those who end up with those visual problems have them earlier in life, then it’s very important that we have myopia-reducing strategies (and use them!) so we can avoid axial elongation, high myopia and its associated risks.

Simply put, eye care practitioners now have many tools at their fingertips to slow myopia progression – reduce the eye length…reduce the risk for future visual impairment!


Title Association of axial length with risk of uncorrectable visual impairment for Europeans with myopia

Importance Myopia (ie, nearsightedness) is becoming the most common eye disorder to cause blindness in younger persons in many parts of the world. Visual impairment due to myopia is associated with structural changes of the retina and the globe because of elongation of the eye axis. How axial length—a sum of the anterior chamber depth, lens thickness, and vitreous chamber depth—and myopia relate to the development of visual impairment over time is unknown.

Objective To evaluate the association between axial length, spherical equivalent, and the risk of visual impairment and to make projections of visual impairment for regions with high prevalence rates.

Design, Setting, and Participants This cross-sectional study uses population-based data from the Rotterdam Study I (1990 to 1993), II (2000 to 2002), and III (2006 to 2008) and the Erasmus Rucphen Family Study (2002 to 2005) as well as case-control data from the Myopia Study (2010 to 2012) from the Netherlands. In total, 15 404 individuals with data on spherical equivalent and 9074 individuals with data on axial length were included in the study; right eyes were used for analyses. Data were analyzed from September 2014 to May 2016.

Design, Setting, and Participants Visual impairment and blindness (defined according to the World Health Organization criteria as a visual acuity less than 0.3) and predicted rates of visual impairment specifically for persons with myopia.

Main Outcomes and Measures  Visual impairment and blindness (defined according to the World Health Organization criteria as a visual acuity less than 0.3) and predicted rates of visual impairment specifically for persons with myopia.

Results Of the 15 693 individuals included in this study, the mean (SD) age was 61.3 (11.4) years, and 8961 (57.1%) were female. Axial length ranged from 15.3 to 37.8 mm; 819 individuals had an axial length of 26 mm or greater. Spherical equivalent ranged from −25 to +14 diopters; 796 persons had high myopia (ie, a spherical equivalent of −6 diopters or less). The prevalence of visual impairment varied from 1.0% to 4.1% in the population-based studies, was 5.4% in the Myopia Study, and was 0.3% in controls. The prevalence of visual impairment rose with increasing axial length and spherical equivalent, with a cumulative incidence (SE) of visual impairment of 3.8% (1.3) for participants aged 75 years with an axial length of 24 to less than 26 mm and greater than 90% (8.1) with an axial length of 30 mm or greater. The cumulative risk (SE) of visual impairment was 5.7% (1.3) for participants aged 60 years and 39% (4.9) for those aged 75 years with a spherical equivalent of −6 diopters or less. Projections of these data suggest that visual impairment will increase 7- to 13-fold by 2055 in high-risk areas.

Conclusions and Relevance  This study demonstrated that visual impairment is associated with axial length and spherical equivalent and may be unavoidable at the most extreme values in this population. Developing strategies to prevent the development of myopia and its complications could help to avoid an increase of visual impairment in the working-age population.

Abstract link is here
